When many people are working on a 100,000-class dust-free workshop, they only know that the cleanliness level should reach 100,000. They are vague about the requirements other than the cleanliness level and do not know much about them.
Today, let us take a closer look at what other requirements there are, which are also indispensable for the construction of a 100,000-class dust-free workshop.
First, it must be the cleanliness level of the dust-free workshop.
A 100,000-class dust-free workshop refers to a clean production environment with an air cleanliness level of 100,000. That is to say, the number of dust particles with a diameter greater than or equal to 0.5 microns per cubic meter of air does not exceed 3,520,000, and the number of dust particles with a diameter greater than or equal to 5 microns does not exceed 29,300. Through high-efficiency filters and other equipment, the air is continuously filtered and purified to maintain this cleanliness level.
Second, it is the temperature and humidity inside the dust-free workshop.
Usually, the temperature of a 100,000-class dust-free workshop is generally controlled at a human comfort temperature: between 18℃-26℃, and the relative humidity of a 100,000-class dust-free workshop is controlled at 45%-65%.
The temperature and humidity of the 100,000-level dust-free workshop are well controlled, which can not only ensure the comfort of the staff for normal operation, but also prevent the product from being affected by environmental factors and causing quality problems.
The 100,000-level dust-free workshop often enters and exits industries with high cleanliness requirements such as food packaging, medical equipment, and electronic product assembly.
If the humidity of the dust-free workshops in these industries is too high, it may cause the products to be damp and breed microorganisms. If the temperature is too low, it may affect the normal operation of some production equipment, thereby affecting the quality and delivery of the products.
Third, it is the management of personnel and materials.
The consciousness of personnel is very important. The 100,000-level dust-free workshop is normally equipped with air shower equipment, but many employees sometimes think that it is troublesome to wear dust-free clothes and go through the air shower room for dust removal when entering and leaving the dust-free workshop. They will directly wear their own clothes to enter, which will cause cross-contamination of the dust-free workshop environment. Therefore, during normal operations, we need to
standardize the entry and exit of personnel and materials in the dust-free workshop, so that we can start from everyone in normal times, jointly maintain the environment of the 100,000-level dust-free workshop, and provide a clean environment for the production of good products.
